24VDC Automatic Mechanical Electric Linear Actuator
Introduction:
The electric linear actuator consists of a motor, a gear and a spindle including a nut.
Stainless steel,Aluminium alloy material,preset limit switches, can bring overheating protection, easy to install, easy to operate; Can replace the hydraulic, pneumatic and other traditional mechanical push and pull products,used in aircraft, ship, car or other products.
Main Parameters:
•Max load 1500N
•Duty cycle 20%(High-speed linear 10%)
•Max static force 2300N
•Operating temperature -20°C~+65°C
•Aluminium outer tube and stroke rod
•Protection IP54 or IP65
•12 or 24 or 36 or 48VDC •Aluminium alloy housing
•Preset limit switches
•Powder metal gears
•Robust
Installation Size:
Performance Datas:
