BAWZF-Y Type Pneumatic Round Damper

BAWZF-Y Type Pneumatic Round Damper

BAWZF-Y Type Pneumatic Round Damper

Product Details:

Place of Origin: TIANJIN CHINA
Brand Name: TIANJIN BELL
Certification: ISO9001 CE
Model Number: BAWYVB

Payment & Shipping Terms:

Minimum Order Quantity: 1 Piece
Price: USD 1500-8000 PIECE
Packaging Details: Plywood case
Delivery Time: 15-30days
Payment Terms: T/T.L/C,Paypal,Western Union
Supply Ability: 1000 pieces per month
Contact Now
Detailed Product Description
Nominal Size: DN800-DN2000 Material: Stainless Steel

Product Features
· BAWZF-Y type pneumatic round dampers match with BAW series pneumatic actuators,Adjustable air flow of larger diameter dampers
· The valve has a variety of materials,Adapt to different working temperatures.
·matched pneumatic actuator must need a pneumatic positioner,Adjustable damper opening degree ,High precision adjustment.


The main parameters of the actuator
1,the use of media: clean, dry,and non-corrosive compressed air
2,working air pressure: 0.3 ~ 0.7MPa
3,ambient temperature: Standard: -20 ℃ ~ + 80 ℃
      High temperature: -20 ℃ ~ + 180 ℃

4,rotation angle: 90 ° ± 3 °
5,Matched pneumatic positioner input and output signal: 4 ~ 20mA (other signals can be customized)



Dimensions

BAWZF-Y Type Pneumatic Round Damper



Nominal pressure:PN0.01MPa

Nominal diameter

DN

Torque

Nm

Various dimensions of dampers body Actuator Dimensions n-φd
D D1 D2 B H1 H2 a1
800 600 975 810 920 210 320 340 600 24-30
900 1075 910 1020 250
1000 1175 1010 1120 28-30
1100 1600 1275 1110 1220 400 361 800 30-30
1200 1375 1210 1320 32-30
1300 1475 1310 1420 34-30
1400 1575 1410 1520 300 36-30
1600 2500 1790 1610 1730 480 1140 40-30
1800 1990 1810 1930 44-30
2000 4000 2190 2010 2130 520 1460 48-30
